  • The oil cylinder loads the external pressure test device.

产品名称:The oil cylinder loads the external pressure test device.

产品型号:BJWTP-500KN

产品量程:500KN

The oil cylinder loads the external pressure test device.立即咨询The oil cylinder loads the external pressure test device.在线留言

<
>

产品简介

BJWTP - 500 kn oil cylinder loading drain outside professional testing drainage pipe external pressure test, pressure testing machine also can detect the concrete pipe, the culvert, cement concrete, reinforced concrete pipe jacking, low pressure drainage pipe, water pipe, prestressed concrete reinforced concrete socket pipe, outlet pipe concrete specimens of external pressure test.

Adopt three - point compression mode.


执行标准

Concrete and reinforced concrete drain pipe (GB/T 11836-99)

Test methods for concrete and reinforced concrete drain pipes (GB/T 16752-2010)


功能特点

1, bar the use of electric screw lift (or oil cylinder lifting), convenient for different diameter drain trials (1000-2600 - mm), can be customized.

2, under the support beams by subsection combined-type, convenient for different length of drain test.

3, base foundation with concrete pouring out the construction plan (by voluntarily.cannot solve, the supplier), and the ground, convenient to a variety of mouth into the drain.

4, load, the cylinder loading, smooth loading, reduction and rapid test space.

Loading 5, meet the national standard regulations and requirements in every level pressure control time, and control the load level can have any programming customer specified.

6, force value directly to KN, according to revoke a strength calculation of the pest.

7 set peak value holding function, software, and data automatic storage, report to edit printing, etc.

8, report can test curve and force value at the same time the information such as save and print, make the test process of realism.

9, beams and the piston stroke limit protection, ensure the safety of test process.

10, high rigid frame design, reduces the interference factors of the test results.

11, control cabinet adopt universal wheel activity type, convenient and test personnel from different parts of the test operation, observe cracks.

Number 12, according to, the table place to work, for users to provide the surface figure shape used at table compiled version of the designed album tool, have dreamed.

The characteristics of flexible, easy to learn, can print test curve and test values;

13, set a powerful automatic reset system software, to eliminate the artificial reset error range and other factors.

14, each set of test area, height, the environment parameters such as temperature can change or fill in according to actual situation.


技术参数

1. Maximum pressure: 500KN.

2. Column spacing: no. 2600mm (can be completed with three levels of test pressure of 1000-2600mm)

3. Test space: 300 x 3000mm (customized according to experiment requirements)

4. Beam adjustment mode: electric screw (electric control button, free adjustment)

5. Beam adjustment range: 300mm ~ 3000mm.

6. Beam movement speed: 100mm/min.

7. Force value accuracy: level 1 (better than + 1% of the indicator)

8. Test force display mode: the computer shows the current pressure time, speed, force value and other parameters in real time.

9, force measurement and control system for microcomputer automatic control, computer display, digital display system, with functions of double screen, loading speed, strength, according to figures with automatic storage, may at any time the query, print and save the test process, and other functions.

Also equipped with printer, can print test report.

10. The fracture load automatically recognizes and records, and damages the automatic recording of load.

11. Achieve the national standard percentage automatic calculation, and issue the data.

12. With overload protection, the power value is 2% automatic shutdown and power failure.

13. Piston stroke: 0-500mm.

14. Upper support beam: 2000mm.

15. Hardwood support length: 1000+1000= 2000mm.

16. Hardwood support spacing: adjustable (easy to adjust)

17. Hardwood support rounded corners: R=12.5mm.

18. Loading mode: electro-hydraulic.

19. Control mode: manual control.

20. Power supply: 380V plus or minus 10%, 220V plus or minus 10%, 50HZ.

21. Machine weight: 3500Kg.

22. External dimension: about 5000x4000x3000mm.
